Features:
- Simple direct coupling reduces installation and commissioning time and improves reliability by eliminating damper linkages. Single screw coupling provides three-point shaft gripping.
- Small, compact design allows installation in tight-fitting locations designed for zone damper actuator applications
- Rotation range 93 degrees CW or CCW
- Fits 3/8 to 1/2 (10 to 13 mm) round or 3/8 (10 mm) square shaft
- On-off, floating and proportional control inputs
- Proportional models are dip switch selectable for DA / RA and DC 0.10 V or DC 2.10 V operation
- DC 0(4) . 20 mA proportional control w/optional 500 Ohm resistor
- Models available with 30 or 60 second running time at 60 Hz
- Long life brushless synchronous drive motor technology – provides constant running time independent of load
- Robust 18 lb-in (2 Nm) and 35 lb-in (4 Nm) torque rating
- Whisper quiet 35 dBA noise rating
- Magnetic clutch – provides over torque protection over the entire range of rotation
- -4 to 125ยฐF (-20 to 52ยฐC) ambient temperature rating
- 100,000 full stroke cycle, 1,500,000 reposition rating
- Manual gear release simplifies setup and field adjustments position feedback (GGX models) provides simple, closed-loop control with accurate position sensing.
- cULus Listed, CE Mark
